| frame |
Macina Lycan 27.5″ Alloy6061 140 |PT750 Bosch BDU37/M2296 |
| fork |
Suntour XCR34 Air 27.5″ LOR 140mm 15×110 |
| rear-shock |
RockShox Deluxe Select 230×62.5 |
| derailleur |
Shimano Deore M5100-11 SGS shadow+ |
| shift-levers |
Shimano Deore M5100-11 |
| brake-front |
Shimano M4100 / MT420 4-Piston |
| brake-rear |
Shimano M4100 / MT420 4-Piston |
| brake-disc-front |
Shimano RT30 CL 203 |
| brake-disc-rear |
Shimano EM300 CL 180 magnet |
| rim-front |
Ambrosio E30 Trail 32H 584x30TC |
| rim-rear |
Ambrosio E30 Trail 32H 584x30TC |
| tire-front |
Schwalbe Nobby Nic Perf. Folding 65-584 |
| tire-rear |
Schwalbe Nobby Nic Perf. Folding 65-584 |
| hub-front |
Shimano TC500B CL 32H 110-15TA |
| hub-rear |
Shimano MT400B CL 32H 148-12TA |
| spokes |
DT Champion 2.0 black / DT Alpine II 2.34 black |
| handlebar |
KTM COMP Trail35 rizer15 760mm |
| stem |
KTM TEAM Trail35 |
| headset |
Acros AICR intern 1.1/8″-1.5″ angle lim |
| grips |
KTM COMP Lock |
| saddle |
KTM Line Sport |
| seat-post |
KTM COMP dropper internal 30.9 T:120 |
| seat-clamp |
KTM Line JD-SC140A – 35,0mm |
| crankset |
KTM E-TRAIL ISIS 170mm Q16 |
| drive |
KMC e11 Sport EPT e-bike |
| sprockets |
Shimano Deore M5100-11 / 11-51 |
| pedals |
MTB-Pedal flat VPE-527 alloy |
| front-light |
Litemove SC-150 150Lux side |
| rear-light |
Supernova TL3Z |
| lock |
ABUS integrated lock IT1 (X-Plus key) |
| motor |
Bosch PERFORMANCE CX BDU3740 |
| battery |
Bosch PowerTUBE 750Wh horizontal |
| battery-capacity |
750 |
| display |
Bosch PURION 200 Display & Remote |
| charger |
Bosch STANDARD Charger 4A |
|
|
|
| Geometrie |
Klik hier voor de geometrie |
| Frame size |
Klik hier voor de juiste maatvoering |
